SANUPS A11J is a redundant True Online uninterruptible power supply system designed for industrial applications.
Powerful and Durable uninterruptible power supply system to protect your mid-size mission-critical equipment with a redundant N+1 configuration.
Industries are becoming more mission-critical in every aspect all while demanding environmental conservation.
SANUPS A11J was designed in response to eco-friendly market needs.
TWO BIRDS WITH ONE STONE
A double conversion system was adopted in order to supply high-quality power. A11J is utilizing a CVCF system which is not affected by the change in input voltage and frequency. It achieves a 93% efficiency rate, while simultaneously reducing running cost, due to a three-level inverter in the DC/AC conversion circuit.
Furthermore, we added a parallel redundant N+1 system to the A11J S-2 in order to improve the reliability even more. For example, if a failure occurs in one of the units in a 5kVA N+1 system, the remaining unit has the capability to carry the 5kVA load. SANUPS A11J S-2 typically supports wafer machines in the semiconductor industry. A11J S-2 is supporting wafer machine and semiconductor industry.
0.9 OUTPUT POWER FACTOR
In recent years, many types of control power supplies built into servers have gained the power factor correction function of the input current. It tends to raise the load power factor. In order to handle this situation, the new model has achieved a 0.9 output power factor. It allows the new model to supply sufficient power even when there is an increasingly high input power factor.
The system can operate on normal mode when the input voltage is -20% to +15% of the nominal input voltage while supplying sufficient output capacity (Max -40% to +15%). With I/O asynchronous mode, the output of 50/60 Hz can be supplied even with an input frequency in the range of 40 Hz to 120 Hz.
HIGH MAINTAINABILITY
A11J is using modules for the battery and the power converter resulting in high maintainability. The modules use a plug-in method, so even if a malfunction occurs during parallel redundant operations, the power module can be replaced quickly while supplying inverter power. This ensures high availability.
A11J has an operation panel which can be removed from the uninterruptible power supply system and placed anywhere you desire. The Operation panel lets you configure the uninterruptible power supply settings easily and quickly.
Our experienced service engineer will support the replacement of batteries or inverters, upon request. Contact UPSweb@sanyo-denki.com anytime.
A11J online uninterruptible power supply system available in 208 V.
(Voltage can be set to 200/208/ 220/230/240)
- 5000VA(4500W)
- 10000VA(9000W)
- 15000VA(13500W)
- 20000VA(18000W)
FEATURES
Double Leak Proof
SANUPS superior double-sealed battery design prevents short circuits and important data loss.
Smooth Air Flow
SANUPS’s improved heat prevention design increases its efficiency and saves more electricity than the previous generation.
Coating Protection
SANUPS’s circuit boards are fully coated through soldering to prevent short-circuiting, caused by dust and insects. Our dust filters are also available as an option.
Auto Health Check
SANUPS periodically performs an automatic battery test for maintenance purposes and sends notifications to the host if an issue occurs.
Noise Reduction
SANUPS emits the lowest electrical noise possible preventing potential problems to the connected loads. The circuits are designed in the acoustic anechoic chamber.
Leak Proof Battery
A11J automatically checks the battery’s condition periodically and sends notifications to the host when a problem occurs. The auto health check-ups extend the battery life.
Wide Input Range
SANUPS A11J provides value to customers with a very wide input voltage window, extremely tight output voltage, and frequency regulation.
Over Current Protection
SANUPS stops excessive current when overcurrent occurs resulting in no voltage change to the utility power and related equipment.
Short Circuit Protection
SANUPS automatically disconnects the circuit in the event of the overload or short circuit, preventing damage to the network and equipment.
LONG PRODUCT LIFE
SANUPS A11J uses only fortified components based on advanced design and technology. Highly reliable ISO9001/14001 certified factory, utilizing a stringent quality control method, results in SANUPS A11J achieving one of the longest product life cycles and one of the highest MTBF rates in the industry.
CASE STUDY
Train Rail Control Systems relied on A11J redundant UPS
Train rail control system supports safe train operations by controlling railroad switches and train signals. The system demands 60 minutes of backup runtime and redundant configuration for high reliability to make sure train operations would not be shut down by blackout or other commercial power problems.
BACKGROUND
The manufacturer exports the rail control system to many countries. Evaluation and statistics showed that the power conditions in some of the countries were highly unreliable. Since the rail control system takes a critical role, reliability and long product life are required for safe operation.
SANUPS SOLUTION
With SANUPS A11J’s N+1 redundant configuration, the uninterruptible power supply system can provide a continuous pure sine wave even if one of the units experiences a malfunction. Moreover, maintenance can be performed without stopping the system ever since SANUPS A11J was employed. As a result, railroad manufacturers were able to reduce maintenance labor costs.
SHUTDOWN ASSISTANT SOFTWARE
SANUPS SOFTWARE is a shutdown assistant. By installing it on the shutdown target computers, your mission-critical equipment can be safely shutdown ensuring system uptime, data integrity, and the ability to maintain business continuity. The application shutdown function even shuts down Microsoft office applications as well.
SANUPS SOFTWARE is innovative software because it also has the capability of a commander server*1 (LAN Card functionality) as well as uninterruptible power supply monitoring for today’s complicated IT infrastructure.
*1 To use the software acts as a commander, please connect commander PC to uninterruptible power supply system via serial cable.
*1 Shutdown target devices need to be powered by the same uninterruptible power supply system that the commander PC is powered by.
A11J-S2 Type
Cabinet Type
| Form | Capacity | Product Name | Part Number | Input | Output | Input Connection | |
|---|---|---|---|---|---|---|---|
| 5kVA | A11J Parallel Online UPS 5000VA | A11J502SA002U | 200V | 200V | I/O Terminal brock | ||
| 10kVA | A11J Parallel Online UPS 10000VA | A11J103SA002U | 200V | 200V | I/O Terminal brock | ||
| 15kVA | A11J Parallel Online UPS 15000VA | A11J153SA002U | 200V | 200V | I/O Terminal brock | ||
| 20kVA | A11J Parallel Online UPS 20000VA | A11J203SA002U | 200V | 200V | I/O Terminal brock |
