SANUPS E11A is an energy efficient and a reliable Uninterruptible Power Supply using a 3-mode system. The 3 available modes are a quality priority, efficiency priority, and active filter.
The E11A Uninterruptible Power Supply automatically selects the best mode based on the power supply and the load power. There is no loss of output when switching between modes.
SANUPS E11A Hybrid-UPS is designed for today’s environment, meets the demand of reliability, functionality, and efficiency. One of the most versatile and high quality in the market.
SAVING ENERGY AND COST
The hybrid type SANUPS E11A automatically selects the most efficient mode of operation for any given power condition. In addition, we added new modes to reach 95% efficiency conversion.
THE THREE MODES
The Uninterruptible Power Supply automatically selects the best mode based on the power supply and the load power. There is no loss of output when switching between modes.
SANUPS E11A is used many places such as airport and traffic systems, supporting our daily lives.
E11A Hybrid Rack Mount UPS available in both AC 120V and 208 V. (Voltage can be set to 100/110/115/120 or 200/208/ 220/230/240 – Rack/ Tower Convertible)
| Model | E11A202B002USP |
|---|---|
| Rated power capacity (apparent/active) | |
| Input | |
| Rated voltage | 208V |
| Frequency range | 46 to 54 Hz (50Hz) 55.2 to 64.8Hz (60Hz) |
| Input connection | NEMA L6-20P |
| Cord Length | 6ft |
| Voltage range | 166.4 to 239.2 V |
| Output | |
| Rated voltage | 208V |
| Voltage harmonic distortion | 3% max. (Linear load) 7% max. (Non-linear load) |
| Rated frequency | 50/60 Hz |
| Topology | Hybrid (Automatic mode change of True Double conversion, Active filter, and Economy mode) |
| Wave form type | Pure sine wave |
| Output Connection | IEC60320 C19x3 |
| Bypass | Built in |
| Number of phases/wires | Single-phase 2-wire |
| Output Voltage range | ±2% Max. |
| Overload capacity | 105%(200ms) |
| Efficiency (Maximum%) | Contact us |
| Power Consumption | 85 to 200 W |
| Expected product life time | 7 years |
| Connection | RS232C, Output Line Control Port, |
| Acoustic noise | 45 dB max. |
| Operating temperature | 0 to 40°C |
| Operating humidity | 20 to 90% |
| Operating Elevation | 3000 m max. |
| Unit Size (HxWxD) | 17.32x22.24x3.39in (440x565x86mm) |
| Unit Weight | 63.93lbs(29kg) |
| Unit Shipping Size (HxWxD) | 22.44x29.53x10.63in (570x750x270mm) |
| Unit Shipping Weight | 72.75lbs(33kg) |
| Certification | UL1778 5th edition (E226092) FCC Part 15 Subpart B Class C |
